Products Microphone Electret Condenser Microphone CMUB6050-15068-403S-1033

Electret Condenser Microphone

CMUB6050-15068-403S-1033

6mm, unidirectional, back plate, 1.5v, 680ohm, -40dB, solder pad microphone, electret condenser microphone, ecm mic, microphone component, mic capsule, microphone capsule
Electret Condenser Microphone-CMUB6050-15068-403S-1033
Electret Condenser Microphone-CMUB6050-15068-403S-1033

Electret Condenser Microphone

Specification
Mechanical Drawing
Datasheet Customized Solutions
REQUEST A QUOTE
Interested in more information for this part?
Fill out the form below and we will be in touch!
Confirm
Length 6 mm
Width 6 mm
Height 5 mm
Directivity Unidirectional
Electret Type Back Plate
Standard Voltage 1.5 Vdc
Output Impedance 680 ohm
Sensitivity -40 ± 3 dB
Signal to Noise Ratio 60 dBA
Terminal Solder Pad
Operating Temperature -20 ~ +70 ℃
0
